| A1205 | Continuous-Time Bipolar Switch | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP, 3-Pin SOT23W | 1.5/15 | -1.5/-15 | |
| A1210 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 85°C, -40°C to 150°C | 3-Pin SIP, 3-Pin SOT23W | 7.8/78 | -7.8/-78 | |
| A1211 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP | 8.7/87 | -9.5/-95 | |
| A1212 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP, 3-Pin SOT23W | 10.7/107 | -11.7/-117 | |
| A1213 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP, 3-Pin SOT23W | 20/200 (max) | -20/-200 (min) | |
| A1214 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP, 3-Pin SOT23W | 30/300 (max) | -30/-300 (min) | |
| APS12170 | Continuous-Time Hall-Effect Latch | Yes | Current | 3.8 | 16.0 | Planar Hall | - | -40°C to 175°C | 3-Pin SIP, 3-Pin SOT23W | 17.5/175 (max) | -17.5/-175 (min) |
Part Number | Description | AEC-Q100 Qualified | Output | Supply Voltage Min (V) | Supply Voltage Max (V) | Magnetic Sensing Dimension | Magnetic Detection | Temp Ranges | Package | Typical BOP (mT/G) | Typical BRP (mT/G) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A1205 | Continuous-Time Bipolar Switch | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP3-Pin SOT23W | 1.5/15 | -1.5/-15 |
| A1210 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 85°C-40°C to 150°C | 3-Pin SIP3-Pin SOT23W | 7.8/78 | -7.8/-78 |
| A1211 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP | 8.7/87 | -9.5/-95 |
| A1212 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP3-Pin SOT23W | 10.7/107 | -11.7/-117 |
| A1213 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP3-Pin SOT23W | 20/200 (max) | -20/-200 (min) |
| A1214 | Continuous-Time Latch Family | Yes | Voltage | 3.8 | 24.0 | 1D | Bipolar | -40°C to 150°C | 3-Pin SIP3-Pin SOT23W | 30/300 (max) | -30/-300 (min) |
| APS12170 | Continuous-Time Hall-Effect Latch | Yes | Current | 3.8 | 16.0 | Planar Hall | -40°C to 175°C | 3-Pin SIP3-Pin SOT23W | 17.5/175 (max) | -17.5/-175 (min) |
Allegro Product Selection Guide (PDF)
