The A19200 device is a Hall-effect-based integrated circuit (IC) that provides a user-friendly and versatile solution for either magnetic encoders or ferrous targets in two-wire applications. The A19200 is offered in the UB package, which integrates the IC and a high temperature ceramic capacitor in a single over-molded SIP package. The integrated capacitor provides enhanced EMC performance reducing, and in most cases eliminating, the need for external components.
The Hall element spacing is optimized for high resolution and small diameter targets, making the A19200 ideally suited for obtaining speed information in wheel speed applications.
The A19200 is available in a lead (Pb) free 2-pin SIP (Suffix UB) package with a 100% matte tin plated leadframe.
| Part Number | Package Type | Temperature | RoHS Compliant |
Part Composition / RoHS Data |
Comments | Samples | Check Stock |
|---|---|---|---|---|---|---|---|
| A19200LUBATN-H-A | 2-lead SIP | -40°C to 150°C | Yes | View Data | Contact your local sales rep |
Check Distributor Stock |
|
| A19200LUBATN-L-A | 2-lead SIP | -40°C to 150°C | Yes | View Data | Contact your local sales rep |
Check Distributor Stock |
|
| ATS19200LSNATN-H | 3-lead SIP | -40°C to 150°C | -- | View Data | Contact your local sales rep |
Check Distributor Stock |
|
| ATS19200LSNATN-H-A | 3-lead SIP | -40°C to 150°C | -- | View Data | Contact your local sales rep |
Check Distributor Stock |
|
| ATS19200LSNATN-L | 3-lead SIP | -40°C to 150°C | -- | View Data | Contact your local sales rep |
Check Distributor Stock |
|
| ATS19200LSNATN-L-A | 3-lead SIP | -40°C to 150°C | -- | View Data | Contact your local sales rep |
Check Distributor Stock |
Allegro’s products are not to be used in any devices or systems, including but not limited to life support devices or systems, in which a failure of Allegro’s product can reasonably be expected to cause bodily harm.
The A19200 is available in a lead (Pb) free 2-pin SIP (Suffix UB) package with a 100% matte tin plated leadframe.
UB Package Documentation
