This is a pre-release product, engineering samples coming soon.

90V Automotive Three-phase Motor Driver with Integrated ARM Cortex Processor

A89224

48 Pin 7x7 EV Package

The A89224 is a high-performance automotive SoC, integrated 3- phase gate drive and precision current sense capability. It is designed for use with advanced stand-alone 3-phase BLDC and PMSM motor control applications.

Request Datasheet and Samples
Navigate

Description

Top Features

Typical Applications

Packaging

The A89224 is a high-performance automotive MCU with a 90V MOSFET driver, designed for advanced motor control 24V and 48V automotive systems. The processor uses the ARM Cortex M4 CPU core running at 40 MHz giving up to 50 MIPS performance. The processor capability is further enhanced by peripheral functions specifically designed for motor control applications. These include a PWM generator and sense current capture systems capable of providing up to 12-bit control precision at up to 20 kHz PWM frequency.

16 general purpose I/O ports provide access to programmable serial communication interfaces, as well as analog and digital inputs and outputs.

The gate driver is an N-channel power MOSFET driver capable of controlling MOSFETs connected in a 3-phase bridge arrangement and is specifically designed for power applications with high-power inductive loads, such as BLDC motors.

  • 5.5 to 90V supply voltage operating range
  • 32-bit ARM Cortex M4 CPU Core
  • Up to 40MHz clock frequency
  • On-chip +/-1% accurate oscillator
  • Programmable clock generator
  • One clock per machine cycle architecture
  • DMA
  • 16 Level interrupt handler
  • SW-DP 2-wire debug
  • On-chip memory
  • HVAC
  • Pump Systems
  • Cooling Fan
  • Seating

48 Pin 7x7 EV Package
