This is a pre-release product, engineering samples coming soon.

Micropower Latches for Battery-Powered and Eco-Conscious Applications

APS12753

APS12753 - Low voltage micropower latch for automotive and industrial applications - MD package

The APS12753 Micropower Hall-effect latch ICs are offered with and without AEC-Q100 qualification for low-voltage applications in Automotive, Industrial and Consumer Applications.

Request Datasheet and Samples
Navigate

Description

Top Features

Typical Applications

Packaging

These sensors are temperature-stable and suited for operation over extended junction temperature ranges up to 165°C. This family of Hall-effect switches provides contactless control of a push-pull output, which actuates in response to a magnetic field applied to the branded package face. Additionally, the Micropower logic allows ultra-low power consumption and operation from 2.2 to 5.5 V.

  • 2.2 to 5.5V operation
  • Ultra-low power consumption (micropower)
  • AEC-Q100 qualified
  • Omnipolar and unipolar latch threshold options
  • Sleep time options
  • High and low sensitivity magnetic latch point options
  • Choice of output polarity
  • Chopper stabilization
    • Low latch point drift over temperature
    • Insensitive to physical stress
  • Push-pull output
  • Solid-state reliability
  • Industry-standard package and pinout
  • Battery-critical applications
  • Brushless DC motors
  • Medical equipment
  • Doors, covers, lids, and tray position detection
  • E-mobility
  • Incremental rotary encoding
  • Smart meters, flow meters
  • Home appliances

The APS12753 is offered in package type MD-3, a standard 3-pin SOT23-3 surface-mount package. The package is lead (Pb) free.
